1986 Dirt Bike XT600Z - XT600Z (1VK) [999] CHASSIS 1 diagram

Reference numbers in this diagram are listed below ā€” scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. šŸ–Ø Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors XT600Z (1VK) [999] - CHASSIS 1
Change View:
FENDER, FRONT
1
Yamaha Motors
FENDER, FRONT46Y-21511-00
Required: 1
FENDER, FRONT
Price unavailable
FENDER, FRONT
1
Yamaha Motors
FENDER, FRONT48Y-21511-00
Required: 1
FENDER, FRONT
Price unavailable
FENDER, FRONT
2
Yamaha Motors
FENDER, FRONT1VJ-21511-10
Required: 1
FENDER, FRONT
Price unavailable
FENDER, FRONT
3
Yamaha Motors
FENDER, FRONT1VJ-21511-00
Required: 1
FENDER, FRONT
Price unavailable
FENDER, FRONT
3
Yamaha Motors
FENDER, FRONT1VJ-21511-10
Required: 1
FENDER, FRONT
Price unavailable
FENDER, FRONT
4
Yamaha Motors
FENDER, FRONT1VJ-21511-20
Required: 1
FENDER, FRONT
Price unavailable
FLAP, FRONT FENDER
5
Yamaha Motors
FLAP, FRONT FENDER43F-21521-00
Required: 1
FLAP, FRONT FENDER
Price unavailable
-10%
BLIND RIVET
6
Yamaha Motors
BLIND RIVET90267-32071-00
Required: 3
RIVET, BLIND
Cross Ship
Leaves in 2-5 days
$2.20
$1.98
You save $0.22
More details
BRACKET, LICENSE
8
Yamaha Motors
BRACKET, LICENSE1VJ-21685-00
Required: 1
BRACKET, LICENSE
Price unavailable
BRACKET, LICENSE
9
Yamaha Motors
BRACKET, LICENSE1VJ-21685-10
Required: 1
BRACKET, LICENSE
Price unavailable
FLAP
10
Yamaha Motors
FLAP1VJ-21621-00
Required: 1
FLAP
Price unavailable
-10%
WASHER
12
Yamaha Motors
WASHER92907-04100-00
Required: 3
WASHER, SPRING
Supersedes: 92906-04100-00
Cross Ship
Leaves in 2-5 days
$9.49
$8.54
You save $0.95
More details
-10%
Washer
13
Yamaha Motors
Washer92907-04600-00
Required: 3
WASHER, PLATE
Supersedes: 92906-04600-00
Cross Ship
Leaves in 2-5 days
$1.85
$1.67
You save $0.19
More details
