1988 Dirt Bike DT125R - DT125R (3DB1) [999] INTAKE diagram
![Yamaha Motors DT125R (3DB1) [999] - INTAKE](https://cdn.crowleymarine.com/yamaha/6MYtWNMb.png)
1
Yamaha Motors
REED VALVE ASSY3BN-13610-00
Required: 1
REED VALVE ASSY
Price unavailable
2
Yamaha Motors
. REED, VALVE2TV-13613-00
Required: 2
. REED, VALVE
Price unavailable
3
Yamaha Motors
. STOPPER, REED VALVE3BN-13616-00
Required: 2
. STOPPER, REED VALVE
Price unavailable
-10%
4
Yamaha Motors
Pan Head Screw98580-03008-00
Required: 6
. SCREW, PAN HEAD
Supersedes: 98501-03008-00
$3.46
You save $0.38
-10%
5
Yamaha Motors
Spring Washer92990-03100-00
Required: 6
. WASHER, SPRING
$8.54
You save $0.95
6
Yamaha Motors
GASKET, VALVE SEAT1TK-13621-00
Required: 1
GASKET, VALVE SEAT
Price unavailable
7
Yamaha Motors
JOINT, CARBURETOR3BN-13565-00
Required: 1
JOINT, CARBURETOR
Price unavailable
-10%
No longer availableSearch Nationwide Inventory
$7.19
You save $0.80
-10%
No longer availableSearch Nationwide Inventory
$0.85
You save $0.09
-10%
10
Yamaha Motors
Plate Washer92907-06600-00
Required: 4
WASHER, PLATE
Supersedes: 92906-06600-00
$0.90
You save $0.10
11
Yamaha Motors
CHAMBER, AIR3BN-13581-00
Required: 1
CHAMBER, AIR
Price unavailable
-10%
$4.94
You save $0.55
-10%
$4.94
You save $0.55
14
Yamaha Motors
CASE, AIR CLEANER 23BN-14421-00
Required: 1
CASE, AIR CLEANER 2
Price unavailable
15
Yamaha Motors
SEAL3BN-14452-00
Required: 1
SEAL
Price unavailable
-10%
16
Yamaha Motors
Tapping Screw97707-50520-00
Required: 6
SCREW, TAPPING
Supersedes: 97706-50520-00
No longer availableSearch Nationwide Inventory
$0.99
You save $0.11
17
Yamaha Motors
JOINT, AIR CLEANER 13BN-14453-00
Required: 1
JOINT, AIR CLEANER 1
Price unavailable
-10%
$7.64
You save $0.85
19
Yamaha Motors
ELEMENT, AIR CLEANER3BN-14451-00
Required: 1
ELEMENT, AIR CLEANER
Price unavailable
20
Yamaha Motors
GUIDE3BN-14458-00
Required: 1
GUIDE
Price unavailable
21
Yamaha Motors
HOLDER, GUIDE3BN-14459-00
Required: 1
HOLDER, GUIDE
Price unavailable
-10%
$9.44
You save $1.05
-10%
23
Yamaha Motors
Wing Nut90175-06008-00
Required: 1
NUT, WING
Supersedes: 90175-06012-00
In stock
Only 2 remaining
$2.48
You save $0.27
24
Yamaha Motors
CAP, CLEANER CASE 13BN-14412-00
Required: 1
CAP, CLEANER CASE 1
Price unavailable
25
Yamaha Motors
SEAL3BN-14467-00
Required: 1
SEAL
Price unavailable
-50%
26
Yamaha Motors
Binding Screw90154-05011-00
Required: 3
SCREW, BINDING
In stock
Only 3 remaining
$2.48
You save $2.48
27
Yamaha Motors
DUCT3BN-14437-00
Required: 1
DUCT
Price unavailable
-10%
$7.64
You save $0.85
-10%
29
Yamaha Motors
Clip90467-11106-00
Required: 1
CLIP
Supersedes: 90467-11102-00
$3.65
You save $0.40
30
Yamaha Motors
DAMPER 13BN-14425-00
Required: 1
DAMPER 1
Price unavailable
-10%
31
Yamaha Motors
Bolt With Washer90119-06123-00
Required: 1
BOLT, WITH WASHER
$7.64
You save $0.85
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
