1988 Dirt Bike DT200U - DT200U (40R0) [010] SEAT diagram
![Yamaha Motors DT200U (40R0) [010] - SEAT](https://cdn.crowleymarine.com/yamaha/oYigYHL2.png)
1
Yamaha Motors
DOUBLE SEAT ASSY34X-W2472-00
Required: 1
DOUBLE SEAT ASSY
Price unavailable
2
Yamaha Motors
.COVER, seat34X-24731-00
Required: 1
.COVER, seat
Price unavailable
3
Yamaha Motors
BAND, seat34X-24734-00
Required: 1
BAND, seat
Price unavailable
4
Yamaha Motors
BRACKET, seat34X-24738-00
Required: 1
BRACKET, seat
Price unavailable
5
Yamaha Motors
BRACKET, seat34X-24748-00
Required: 1
BRACKET, seat
Price unavailable
-10%
$7.64
You save $0.85
-15%
7
Yamaha Motors
Plain Washer92990-08200-00
Required: 2
WASHER, plain
Supersedes: 92901-08200-00
In stock
Only 1 remaining
$2.59
You save $0.46
-15%
8
Yamaha Motors
Spring Washer92990-08100-00
Required: 2
WASHER, spring
Supersedes: 92901-08100-00
In stock
5+ in stock
$4.76
You save $0.84
-10%
9
Yamaha Motors
Nut95303-08700-00
Required: 2
NUT
Supersedes: 95301-08700-00
No longer availableSearch Nationwide Inventory
$3.19
You save $0.35
10
Yamaha Motors
HOOK, seat34X-24754-00
Required: 1
HOOK, seat
Price unavailable
11
Yamaha Motors
PIN34X-24774-00
Required: 1
PIN
Price unavailable
12
Yamaha Motors
BRACKET, seat10V-24728-01
Required: 1
BRACKET, seat
Price unavailable
13
Yamaha Motors
LEVER, seat10V-24776-01
Required: 1
LEVER, seat
Price unavailable
14
Yamaha Motors
Circle Clip99001-06600-00
Required: 1
CIRCLIP
Supersedes: 93430-06005-00
In stock
5+ in stock
$3.54
15
Yamaha Motors
SPRING, torsion90508-23565
Required: 1
SPRING, torsion
Price unavailable
-10%
No longer availableSearch Nationwide Inventory
$8.09
You save $0.90
-10%
$10.79
You save $1.20
-10%
$2.75
You save $0.30
19
Yamaha Motors
PIN10V-24784-00
Required: 1
PIN
Price unavailable
-10%
$8.54
You save $0.95
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
