1988 Dirt Bike YZ490 - YZ490 (2WH0) [030] SEAT diagram
![Yamaha Motors YZ490 (2WH0) [030] - SEAT](https://cdn.crowleymarine.com/yamaha/Ner5KK8h.png)
-10%
1
Yamaha Motors
SEMI-DOUBLE SEAT ASSEMBLY1LX-24770-10-00
Required: 1
SEMI-DOBLE SEAT ASSY
Supersedes: 1LX-24770-00-00
No longer availableSearch Nationwide Inventory
$272.69
You save $30.30
-10%
1
Yamaha Motors
SEMI-DOUBLE SEAT ASSEMBLY1LX-24770-10-00
Required: 1
SEMI-DOUBLE SEAT ASSY
No longer availableSearch Nationwide Inventory
$272.69
You save $30.30
-10%
No longer availableSearch Nationwide Inventory
$153.89
You save $17.10
-10%
No longer availableSearch Nationwide Inventory
$159.29
You save $17.70
-10%
3
Yamaha Motors
Seat Bracket5X6-24748-10-00
Required: 1
.BRACKET, seat
No longer availableSearch Nationwide Inventory
$8.99
You save $1.00
-10%
4
Yamaha Motors
Screw98517-06012-00
Required: 2
.SCREW, pan head
Supersedes: 92501-06012-00
$3.69
You save $0.41
-15%
5
Yamaha Motors
Plate Washer92990-06600-00
Required: 2
.WASHER, plate
Supersedes: 92901-06600-00
In stock
5+ in stock
$2.51
You save $0.44
-10%
6
Yamaha Motors
Seat Bracket1LX-24738-01-00
Required: 2
.BRACKET, seat
No longer availableSearch Nationwide Inventory
$17.99
You save $2.00
-15%
7
Yamaha Motors
Flange Bolt95817-06012-00
Required: 4
.BOLT, flange
Supersedes: 95801-06012-00
In stock
Only 2 remaining
$1.66
You save $0.29
-10%
8
Yamaha Motors
Seat Damper509-24724-00-00
Required: 1
.DAMPER, seat
$10.79
You save $1.20
-10%
No longer availableSearch Nationwide Inventory
$8.09
You save $0.90
-10%
10
Yamaha Motors
Flange Bolt (3JPE)95024-08016-00
Required: 2
BOLT, flange
Supersedes: 95023-08016-00
$9.44
You save $1.05
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
