1991 Dirt Bike DT125R - DT125R (3PY3) [999] CRANKCASE COVER 1 diagram
![Yamaha Motors DT125R (3PY3) [999] - CRANKCASE COVER 1](https://cdn.crowleymarine.com/yamaha/bfeBA9Zg.png)
1
Yamaha Motors
COVER, CRANKCASE 13NC-E5411-00
Required: 1
COVER, CRANKCASE 1
Price unavailable
-10%
2
Yamaha Motors
CRANKCASE SEAL3ET-15379-00-00
Required: 1
SEAL, CRANKCASE
$35.09
You save $3.90
-10%
3
Yamaha Motors
Pan Head Screw90157-06096-00
Required: 6
SCREW, PAN HEAD
No longer availableSearch Nationwide Inventory
$6.74
You save $0.75
-10%
$8.54
You save $0.95
5
Yamaha Motors
COVER, CRANKCASE 23NC-E5421-00
Required: 1
COVER, CRANKCASE 2
Price unavailable
-10%
$30.59
You save $3.40
-15%
7
Yamaha Motors
Dowel Pin99530-10114-00
Required: 2
PIN, DOWEL
Supersedes: 99530-10014-00
$2.25
You save $0.40
8
Yamaha Motors
GASKET, CRANKCASE COVER 13NC-E5451-00
Required: 1
GASKET, CRANKCASE COVER 1
Price unavailable
9
Yamaha Motors
PLUG, OIL2VR-E5363-00
Required: 1
PLUG, OIL
Price unavailable
-15%
In stock
Only 3 remaining
$7.64
You save $1.35
-50%
11
Yamaha Motors
Pan Head Screw98517-06030-00
Required: 5
SCREW, PAN HEAD
Supersedes: 92516-06030-00
In stock
Only 2 remaining
$1.73
You save $1.73
-10%
12
Yamaha Motors
Pan Screw98507-06040-00
Required: 1
SCREW, PAN HEAD
Supersedes: 98506-06040-00
$2.90
You save $0.32
-10%
13
Yamaha Motors
FLANGE BOLT (JF2)95817-08080-00
Required: 1
BOLT, FLANGE
Supersedes: 95816-08080-00
$4.94
You save $0.55
-10%
14
Yamaha Motors
Gasket90201-08087-00
Required: 1
WASHER, PLATE
$3.56
You save $0.40
15
Yamaha Motors
COVER, OIL PUMP3NC-E5416-00
Required: 1
COVER, OIL PUMP
Price unavailable
16
Yamaha Motors
GASKET, OIL PUMP COVER 13NC-E5456-00
Required: 1
GASKET, OIL PUMP COVER 1
Price unavailable
-50%
17
Yamaha Motors
Pan Head Screw98517-06030-00
Required: 3
SCREW, PAN HEAD
Supersedes: 92516-06030-00
In stock
Only 2 remaining
$1.73
You save $1.73
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
