1991 Dirt Bike DT125R - DT125R (3PY3) [999] RADIATOR & HOSE diagram
![Yamaha Motors DT125R (3PY3) [999] - RADIATOR & HOSE](https://cdn.crowleymarine.com/yamaha/tbe9CAjZ.png)
1
Yamaha Motors
JOINT 13NC-E2469-00
Required: 1
JOINT 1
Price unavailable
2
Yamaha Motors
GASKET, COVER3NC-E2414-00
Required: 1
GASKET, COVER
Price unavailable
-10%
3
Yamaha Motors
98516-06020-0092506-06020-00
Required: 3
SCREW, PAN HEAD
No longer availableSearch Nationwide Inventory
$1.98
You save $0.22
4
Yamaha Motors
PIPE 13BN-12481-00
Required: 1
PIPE 1
Price unavailable
-10%
5
Yamaha Motors
Pan Head Screw98516-06012-00
Required: 1
SCREW, PAN HEAD
Supersedes: 92506-06012-00
No longer availableSearch Nationwide Inventory
$2.07
You save $0.23
-15%
6
Yamaha Motors
O-Ring93210-12790-00
Required: 1
O-RING
Supersedes: 93210-12327-00
In stock
5+ in stock
$7.22
You save $1.27
-10%
7
Yamaha Motors
Pan Head Screw98516-06012-00
Required: 1
SCREW, PAN HEAD
Supersedes: 92506-06012-00
No longer availableSearch Nationwide Inventory
$2.07
You save $0.23
8
Yamaha Motors
PIPE 23BN-12482-00
Required: 1
PIPE 2
Price unavailable
-10%
9
Yamaha Motors
90450-22M14-0090450-25037-00
Required: 2
HOSE CLAMP ASSY
Supersedes: 90450-22017-00
No longer availableSearch Nationwide Inventory
$9.89
You save $1.10
10
Yamaha Motors
PIPE 33BN-12483-00
Required: 1
PIPE 3
Price unavailable
-10%
11
Yamaha Motors
Hose Clamp Assembly90450-28001-00
Required: 2
HOSE CLAMP ASSY
Supersedes: 90450-28014-00
$14.84
You save $1.65
12
Yamaha Motors
RADIATOR ASSY3BN-12460-00
Required: 1
RADIATOR ASSY
Price unavailable
13
Yamaha Motors
. CAP, RADIATOR1KT-12462-00
Required: 1
. CAP, RADIATOR
Price unavailable
-10%
$8.54
You save $0.95
-50%
15
Yamaha Motors
Flange Bolt95817-06020-00
Required: 2
BOLT, FLANGE
Supersedes: 91001-06020-00
In stock
Only 2 remaining
$1.75
You save $1.75
-10%
16
Yamaha Motors
COLLAR90387-07020-00
Required: 2
COLLAR
Supersedes: 90387-07390-00
$8.54
You save $0.95
-10%
17
Yamaha Motors
Plate Washer90201-06072-00
Required: 2
WASHER, PLATE
$9.44
You save $1.05
18
Yamaha Motors
THERMOSTAT34X-12411-00
Required: 1
THERMOSTAT
Price unavailable
-20%
19
Yamaha Motors
O-Ring93210-27778-00
Required: 1
O-RING
Supersedes: 93210-27194-00
In stock
Only 1 remaining
$7.59
You save $1.90
20
Yamaha Motors
UNION90405-06042
Required: 1
UNION
Price unavailable
-50%
In stock
Only 1 remaining
$2.02
You save $2.02
-10%
22
Yamaha Motors
Union Bolt90401-06003-00
Required: 1
BOLT, UNION
Supersedes: 90401-06115-00
No longer availableSearch Nationwide Inventory
$5.04
You save $0.56
23
Yamaha Motors
PIPE 63NC-E2476-00
Required: 1
PIPE 6
Price unavailable
24
Yamaha Motors
PIPE 43NC-E2484-00
Required: 1
PIPE 4
Price unavailable
-10%
$9.44
You save $1.05
26
Yamaha Motors
UNION90405-06042
Required: 1
UNION
Price unavailable
-50%
In stock
Only 1 remaining
$2.02
You save $2.02
-10%
28
Yamaha Motors
Union Bolt90401-06003-00
Required: 1
BOLT, UNION
Supersedes: 90401-06115-00
No longer availableSearch Nationwide Inventory
$5.04
You save $0.56
-10%
$8.54
You save $0.95
30
Yamaha Motors
BOLT97006-05012
Required: 1
BOLT
Price unavailable
-10%
31
Yamaha Motors
Spring Washer92907-05100-00
Required: 1
WASHER, SPRING
Supersedes: 92906-05100-00
$8.54
You save $0.95
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
