1992 Dirt Bike XTZ660 - XTZ660 (4BW2) [999] ALTERNATE FOR CHASSIS diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors XTZ660 (4BW2) [999] - ALTERNATE FOR CHASSIS
Change View:
BRACKET, LICENSE
2
Yamaha Motors
BRACKET, LICENSE2KF-21685-11
Required: 1
BRACKET, LICENSE
Price unavailable
FLAP
3
Yamaha Motors
FLAP1VJ-21621-00
Required: 1
FLAP
Price unavailable
-10%
Washer
5
Yamaha Motors
Washer92907-04200-00
Required: 4
WASHER, PLAIN
Supersedes: 92906-04200-00
Cross Ship
Leaves in 2-5 days
$1.80
$1.62
You save $0.18
More details
-10%
Plate Washer
8
Yamaha Motors
Plate Washer90201-044H9-00
Required: 1
WASHER, PLATE
Supersedes: 90201-044A2-00
Cross Ship
Leaves in 2-5 days
$9.49
$8.54
You save $0.95
More details
-10%
BLIND RIVET
9
Yamaha Motors
BLIND RIVET90267-40090-00
Required: 1
RIVET, BLIND
Cross Ship
Leaves in 2-5 days
$4.45
$4.00
You save $0.45
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
