1994 Dirt Bike TT250R - TT250R (4MR1) [010] OIL PUMP diagram
![Yamaha Motors TT250R (4MR1) [010] - OIL PUMP](https://cdn.crowleymarine.com/yamaha/pivLesyZ.png)
1
Yamaha Motors
OIL PUMP ASSY4GY-13300-00
Required: 1
OIL PUMP ASSY
Price unavailable
-10%
2
Yamaha Motors
Pump Driven Gear4GY-13326-00-00
Required: 1
P97 GEAR, PUMP DRIVEN 2
$61.19
You save $6.80
-50%
3
Yamaha Motors
Circle Clip99009-11400-00
Required: 1
P97 CIRCLIP (24H)
In stock
Only 1 remaining
$4.75
You save $4.75
-10%
4
Yamaha Motors
Pump Cover Gasket4GY-13329-00-00
Required: 1
P97 GASKET, PUMP COVER
$6.74
You save $0.75
5
Yamaha Motors
P97 COVER, PUMP 24GY-13356-00
Required: 1
P97 COVER, PUMP 2
Price unavailable
6
Yamaha Motors
P97 COVER, PUMP GEAR4GY-13327-00
Required: 1
P97 COVER, PUMP GEAR
Price unavailable
-50%
7
Yamaha Motors
Pan Head Screw97885-06035-00
Required: 3
488 SCREW, PAN HEAD
Supersedes: 98580-06035-00
In stock
Only 2 remaining
$3.25
You save $3.25
-10%
8
Yamaha Motors
Tank Cap Gasket90430-06156-00
Required: 1
P97 GASKET (3Y1)
$3.96
You save $0.44
-10%
9
Yamaha Motors
Oil Strainer22F-13411-01-00
Required: 1
P97 STRAINER, OIL
Supersedes: 22F-13411-00-00
$29.69
You save $3.30
-10%
10
Yamaha Motors
Oil Cleaner Element Assembly1UY-13440-02-00
Required: 1
P97 OIL FILTER,YFM350 YFM400
$16.64
You save $1.85
-10%
11
Yamaha Motors
O-Ring93210-54175-00
Required: 1
P97 O-RING (341)
$12.59
You save $1.40
-50%
12
Yamaha Motors
O-Ring93210-07135-00
Required: 2
P97 O-RING (583 OIL D
In stock
Only 2 remaining
$3.50
You save $3.50
-10%
13
Yamaha Motors
Oil Element Cover4GY-13447-00-00
Required: 1
P97 COVER, OIL ELEMENT
No longer availableSearch Nationwide Inventory
$73.79
You save $8.20
-10%
14
Yamaha Motors
BOLT90109-06419-00
Required: 1
P97 BOLT(583 OIL DRAIN)
$8.54
You save $0.95
15
Yamaha Motors
BOLT91316-0b070
Required: 1
BOLT
Price unavailable
-6%
No longer availableSearch Nationwide Inventory
$2.15
You save $0.15
-10%
17
Yamaha Motors
Gasket90430-06014-00
Required: 1
D95 GASKET P97
$8.09
You save $0.90
-10%
18
Yamaha Motors
90163-06002-0090153-06029-00
Required: 1
SCREW, HEXAGON TSI PE90002
Supersedes: 90153-06045-00
$10.34
You save $1.15
-10%
19
Yamaha Motors
Straight Screw Plug90105-122A1-00
Required: 3
207 PLUG, STRAIGHT SCREW
Supersedes: 90340-12065-00
$2.34
You save $0.26
-10%
20
Yamaha Motors
Tank Cap Gasket90430-12213-00
Required: 3
P97 GASKET(3FD)
$5.84
You save $0.65
-10%
21
Yamaha Motors
Delivery Pipe 14GY-13161-00-00
Required: 1
PIPE, DELIVERY 1
No longer availableSearch Nationwide Inventory
$108.89
You save $12.10
-10%
22
Yamaha Motors
Delivery Pipe 14GY-13161-00-00
Required: 2
PIPE, DELIVERY 1
No longer availableSearch Nationwide Inventory
$108.89
You save $12.10
-50%
In stock
Only 2 remaining
$1.73
You save $1.73
-10%
24
Yamaha Motors
UNION BOLT90401-08133-00
Required: 1
BOLT, UNION (3AJ)
$10.34
You save $1.15
-10%
25
Yamaha Motors
Gasket90201-08087-00
Required: 2
P97 WASHER, PLATE
$3.56
You save $0.40
-10%
26
Yamaha Motors
Relief Valve Assembly4GY-13490-00-00
Required: 1
RELIEF VALVE ASSY
$33.29
You save $3.70
-50%
In stock
Only 3 remaining
$2.02
You save $2.02
-10%
No longer availableSearch Nationwide Inventory
$3.15
You save $0.35
-10%
29
Yamaha Motors
Flange Bolt (4MY)95027-06012-00
Required: 1
BOLT, WASHER BASE
Supersedes: 90105-06553-00
$3.78
You save $0.42
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
