1991 Scooter CY90 - CY90 (4CX1) [999] AIR SHROUD & FAN diagram
![Yamaha Motors CY90 (4CX1) [999] - AIR SHROUD & FAN](https://cdn.crowleymarine.com/yamaha/ArtMWOmM.png)
1
Yamaha Motors
AIR SHROUD, CYLINDER 13WF-12651-00
Required: 1
AIR SHROUD, CYLINDER 1
Price unavailable
-10%
$1.57
You save $0.18
3
Yamaha Motors
AIR SHROUD, CYLINDER 33WF-12653-01
Required: 1
AIR SHROUD, CYLINDER 3
Price unavailable
-10%
$2.97
You save $0.33
-15%
$2.80
You save $0.50
-20%
6
Yamaha Motors
Pan Head Screw98517-06020-00
Required: 2
SCREW, PAN HEAD
Supersedes: 98516-06020-00
In stock
Only 5 remaining
$1.88
You save $0.47
7
Yamaha Motors
WASHER, PLATE90201-06815
Required: 2
WASHER, PLATE
Price unavailable
-10%
8
Yamaha Motors
PAN HEAD TAP SCREW97707-60540-00
Required: 1
SCREW, TAPPING
Supersedes: 97702-60540-00
$9.44
You save $1.05
-10%
9
Yamaha Motors
Air Shroud Damper4FW-12658-00-00
Required: 3
DAMPER, AIR SHROUD 1
Supersedes: 3KJ-12658-01-00
No longer availableSearch Nationwide Inventory
$9.44
You save $1.05
10
Yamaha Motors
FAN3WF-12611-00
Required: 1
FAN
Price unavailable
-15%
In stock
5+ in stock
$8.07
You save $1.42
-20%
12
Yamaha Motors
Pan Head Screw98507-06014-00
Required: 3
SCREW, PAN HEAD
Supersedes: 98501-06014-00
In stock
Only 1 remaining
$7.59
You save $1.90
-15%
13
Yamaha Motors
Spring Washer92995-06100-00
Required: 3
WASHER, SPRING
Supersedes: 92990-06100-00
In stock
5+ in stock
$3.02
You save $0.53
-15%
14
Yamaha Motors
Plate Washer92990-06600-00
Required: 3
WASHER, PLATE
Supersedes: 92901-06600-00
In stock
5+ in stock
$2.51
You save $0.44
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
