1999 Scooter TZR50 - TZR50 (4YV2) [999] EQUIPO ELECTRICO 1 diagram
![Yamaha Motors TZR50 (4YV2) [999] - EQUIPO ELECTRICO 1](https://cdn.crowleymarine.com/yamaha/GgTAwBeh.png)
1
Yamaha Motors
C.D.I. UNIT ASSY4YV-H5540-00
Required: 1
C.D.I. UNIT ASSY
Price unavailable
-10%
2
Yamaha Motors
Bolt (3JB)91314-06020-00
Required: 2
BOLT
Supersedes: 91311-06020-00
$2.39
You save $0.27
-15%
3
Yamaha Motors
Plate Washer92990-06600-00
Required: 2
WASHER, PLATE
Supersedes: 92902-06600-00
In stock
5+ in stock
$2.51
You save $0.44
4
Yamaha Motors
PLUG CAP ASSY2JW-H2370-00
Required: 1
PLUG CAP ASSY
Price unavailable
5
Yamaha Motors
NEUTRAL SWITCH ASSY3NC-H2540-00
Required: 1
NEUTRAL SWITCH ASSY
Price unavailable
6
Yamaha Motors
GASKET90430-09824
Required: 1
GASKET
Price unavailable
7
Yamaha Motors
SCREW, PAN HEAD98501-04006
Required: 1
SCREW, PAN HEAD
Price unavailable
8
Yamaha Motors
WASHER, TOOTH90205-04802
Required: 1
WASHER, TOOTH
Price unavailable
-10%
9
Yamaha Motors
Thermo Switch Assembly11H-82560-00-00
Required: 1
THERMO SWITCH ASSY
No longer availableSearch Nationwide Inventory
$49.49
You save $5.50
10
Yamaha Motors
STARTING MOTOR ASSY4YV-H1800-00
Required: 1
STARTING MOTOR ASSY
Price unavailable
-50%
11
Yamaha Motors
Bolt (4MY)91317-06025-00
Required: 2
BOLT, HEXAGON SOCKET HEAD
Supersedes: 91312-06025-00
In stock
Only 1 remaining
$1.33
You save $1.33
12
Yamaha Motors
CLAMP90464-13804
Required: 6
CLAMP
Price unavailable
-10%
13
Yamaha Motors
BTG-GT4LB-S0-00BTY-YT4LB-S0-00
Required: 1
BATTERY ASSY (GSY YT4L-BS)
Supersedes: 3UC-82100-11-00
No longer availableSearch Nationwide Inventory
$39.56
You save $4.39
14
Yamaha Motors
BAND, BATTERY4BA-H2131-00
Required: 1
BAND, BATTERY
Price unavailable
15
Yamaha Motors
SEAT, BATTERY4BA-H2122-00
Required: 1
SEAT, BATTERY
Price unavailable
16
Yamaha Motors
VOLTAGE REGULATOR ASSY4YV-H1910-00
Required: 1
VOLTAGE REGULATOR ASSY
Price unavailable
-10%
17
Yamaha Motors
BOLT97021-06030-00
Required: 1
BOLT
Supersedes: 97001-06030-00
No longer availableSearch Nationwide Inventory
$0.85
You save $0.09
18
Yamaha Motors
RECTIFIER ASSY4ML-81970-00
Required: 1
RECTIFIER ASSY
Price unavailable
-50%
19
Yamaha Motors
Flange Bolt95817-06020-00
Required: 1
BOLT, FLANGE
Supersedes: 95826-06020-00
In stock
Only 2 remaining
$1.75
You save $1.75
-10%
20
Yamaha Motors
STEERING LOCK MAIN SWITCH3TU-82501-00-00
Required: 1
MAIN SWITCH STEERING LOCK
No longer availableSearch Nationwide Inventory
$207.89
You save $23.10
21
Yamaha Motors
BOLT, WITH WASHER97502-06516
Required: 2
BOLT, WITH WASHER
Price unavailable
22
Yamaha Motors
STOP SWITCH ASSY4BA-H2530-00
Required: 1
STOP SWITCH ASSY
Price unavailable
23
Yamaha Motors
WIRE HARNESS ASSY4YV-H2590-00
Required: 1
WIRE HARNESS ASSY
Price unavailable
24
Yamaha Motors
BAND4BA-H2155-00
Required: 1
BAND
Price unavailable
25
Yamaha Motors
FUSE4BA-H2151-00
Required: 1
FUSE
Price unavailable
26
Yamaha Motors
RESISTOR ASSY4BA-H5370-00
Required: 1
RESISTOR ASSY
Price unavailable
27
Yamaha Motors
DIODE ASSY4YV-H1980-00
Required: 2
DIODE ASSY
Price unavailable
28
Yamaha Motors
BAND, SWITCH CORD5T8-H3936-10
Required: 1
BAND, SWITCH CORD
Price unavailable
29
Yamaha Motors
OIL LEVEL GAUGE ASSY3MA-85720-11
Required: 1
OIL LEVEL GAUGE ASSY
Price unavailable
30
Yamaha Motors
STARTER RELAY ASSY (2XX-00)2XX-81940-00
Required: 1
STARTER RELAY ASSY (2XX-00)
Price unavailable
-10%
31
Yamaha Motors
Side Stand Switch3LD-82566-50-00
Required: 1
SWITCH, SIDE STAND
No longer availableSearch Nationwide Inventory
$58.49
You save $6.50
32
Yamaha Motors
BOLT, HEXAGON SOCKET HEAD90110-05822
Required: 2
BOLT, HEXAGON SOCKET HEAD
Price unavailable
-10%
33
Yamaha Motors
Starter Relay25G-81950-02-00
Required: 1
RELAY ASSY (25G-01)
Supersedes: 25G-81950-01-00
$46.79
You save $5.20
-10%
34
Yamaha Motors
RELAY ASSEMBLY3GM-81950-00-00
Required: 1
RELAY ASSY (3GM-00)
No longer availableSearch Nationwide Inventory
$48.59
You save $5.40
-10%
35
Yamaha Motors
Flasher Relay Assembly29G-83350-20-00
Required: 1
FLASHER RELAY ASSY
$81.89
You save $9.10
36
Yamaha Motors
HORN4MJ-H3371-00
Required: 1
HORN
Price unavailable
37
Yamaha Motors
BOLT, WITH WASHER97506-06412
Required: 1
BOLT, WITH WASHER
Price unavailable
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
