1999 Scooter YN100 - YN100 (5KK1) [99C] GRUPO CONMUTADORES CON MANETAS diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors YN100 (5KK1) [99C] - GRUPO CONMUTADORES CON MANETAS
Change View:
LEVER HOLDER ASSY (LEFT)
1
Yamaha Motors
LEVER HOLDER ASSY (LEFT)5AD-H2910-02
Required: 1
LEVER HOLDER ASSY (LEFT)
Price unavailable
. HOLDER, LEVER UPPER 1
2
Yamaha Motors
. HOLDER, LEVER UPPER 15AD-H2912-02
Required: 1
. HOLDER, LEVER UPPER 1
Price unavailable
. HOLDER, LEVER LOWER 1
3
Yamaha Motors
. HOLDER, LEVER LOWER 15AD-H2913-00
Required: 1
. HOLDER, LEVER LOWER 1
Price unavailable
-10%
Button head bolt
4
Yamaha Motors
Button head bolt92014-06020-00
Required: 1
. BOLT, BUTTON HEAD
Cross Ship
Leaves in 2-5 days
$10.49
$9.44
You save $1.05
More details
. LEVER 1
5
Yamaha Motors
. LEVER 15AD-H3912-01
Required: 1
. LEVER 1
Price unavailable
-10%
LEVER NUT
7
Yamaha Motors
LEVER NUT3VL-H3916-00-00
Required: 1
. NUT, LEVER FITTING
Cross Ship
Leaves in 2-5 days
$3.55
$3.19
You save $0.35
More details
-10%
Spring
8
Yamaha Motors
Spring4KH-H3962-00-00
Required: 1
. SPRING
Cross Ship
Leaves in 2-5 days
$1.45
$1.30
You save $0.15
More details
-10%
STOP SWITCH ASSEMBLY
9
Yamaha Motors
STOP SWITCH ASSEMBLY5XL-H3980-00-00
Required: 1
FRONT STOP SWITCH ASSY
Supersedes: 5AD-H3980-01-00
Cross Ship
Leaves in 2-5 days
$37.99
$34.19
You save $3.80
More details
SWITCH, HANDLE 1
10
Yamaha Motors
SWITCH, HANDLE 15AD-H3976-10
Required: 1
SWITCH, HANDLE 1
Price unavailable
STARTER SWITCH ASSY
11
Yamaha Motors
STARTER SWITCH ASSY5AD-H3970-10
Required: 1
STARTER SWITCH ASSY
Price unavailable
SWITCH, HANDLE 2
12
Yamaha Motors
SWITCH, HANDLE 25AD-H3975-10
Required: 1
SWITCH, HANDLE 2
Price unavailable
BEAM SWITCH ASSY
13
Yamaha Motors
BEAM SWITCH ASSY5AD-H3950-10
Required: 1
BEAM SWITCH ASSY
Price unavailable
SWITCH
14
Yamaha Motors
SWITCH5AD-H396U-10
Required: 1
SWITCH
Price unavailable

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
