1994 Sport Bike FZR1000 - FZR1000 (3LH6) [999] ALTERNATE diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status

Click on

to see part

Ships Now

Ships Later

Out of Stock

Yamaha Motors FZR1000 (3LH6) [999] - ALTERNATE

Change View:

-10%

Yamaha Motors

BODY ASSEMBLY4FM-84330-41-00

Required: 1

BODY ASSY

No longer availableSearch Nationwide Inventory

~~$130.99~~

$117.89

You save $13.10

More details

-10%

Yamaha Motors

Lens Assembly4FM-84320-40-00

Required: 1

LENS ASSY

No longer availableSearch Nationwide Inventory

~~$188.99~~

$170.09

You save $18.90

More details

-10%

Yamaha Motors

Lens Assembly4FM-8432A-40-00

Required: 1

LENS ASSY

No longer availableSearch Nationwide Inventory

~~$390.65~~

$351.59

You save $39.06

More details

Yamaha Motors

BULB, HEADLIGHT1FM-84314-HO

Required: 2

BULB, HEADLIGHT

Price unavailable

-10%

Yamaha Motors

Socket Cover4JG-84397-00-00

Required: 2

COVER, SOCKET

~~$15.49~~

$13.94

You save $1.55

More details

-10%

Yamaha Motors

Adjusting Nut51L-84334-00-00

Required: 4

NUT, ADJUSTING

~~$9.99~~

$8.99

You save $1.00

-10%

PLUG

~~$6.49~~

$5.84

You save $0.65

More details

Yamaha Motors

CAP3GM-84378-00-P3

Required: 1

CAP

Price unavailable

-10%

Yamaha Motors

Truss Screw97707-50012-00

Required: 2

SCREW, TAPPING

Supersedes: 90167-05041-00

~~$4.63~~

$4.17

You save $0.46

More details

Yamaha Motors

CORD, HEADLIGHT3GM-84359-70

Required: 1

CORD, HEADLIGHT

Price unavailable

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
