1996 Sport Bike YZF750SP - YZF750SP (4HT4) [010] CYLINDER diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors YZF750SP (4HT4) [010] - CYLINDER
Change View:
-10%
O-Ring
3
Yamaha Motors
O-Ring93210-76211-00
Required: 4
O-RING
Cross Ship
Leaves in 2-5 days
$6.49
$5.84
You save $0.65
More details
-10%
Flange Bolt (4MY)
4
Yamaha Motors
Flange Bolt (4MY)95027-06012-00
Required: 2
BOLT, FLANGE
Cross Ship
Leaves in 2-5 days
$4.20
$3.78
You save $0.42
More details
-10%
Gasket
5
Yamaha Motors
Gasket90430-06014-00
Required: 2
GASKET
Cross Ship
Leaves in 2-5 days
$8.99
$8.09
You save $0.90
More details
-10%
CYLINDER HEAD GASKET
7
Yamaha Motors
CYLINDER HEAD GASKET3FV-11181-00-00
Required: 1
GASKET, CYLINDER HEAD 1
Cross Ship
Leaves in 2-5 days
$99.99
$89.99
You save $10.00
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
