2016 Sport Bike YZF-R1 RaceBase - YZF-R1 RaceBase (BH32) [010] HEADLIGHT diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status

Click on

9

to see part

9

Ships Now

9

Ships Later

9

Out of Stock

Yamaha Motors YZF-R1 RaceBase (BH32) [010] - HEADLIGHT

Change View:

HEADLIGHT ASSY

1

Yamaha Motors

HEADLIGHT ASSY2CR-84300-10

Required: 1

HEADLIGHT ASSY

Price unavailable

-10%

Spring Nut

Spring Nut90183-051A6-00

NUT, SPRING

~~$6.49~~

$5.84

You save $0.65

-10%

BOLT

BOLT90111-05011-00

BOLT,HEX. SOCKET BUTTON

~~$6.49~~

$5.84

You save $0.65

-10%

COLLAR

COLLAR90387-06302-00

COLLAR

~~$6.49~~

$5.84

You save $0.65

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
