1991 Street Bike TZ250 - TZ250 (3YL1) [999] METER diagram
![Yamaha Motors TZ250 (3YL1) [999] - METER](https://cdn.crowleymarine.com/yamaha/fuZfmf3d.png)
-10%
1
Yamaha Motors
TACHOMETER ASSEMBLY3YL-83540-00-00
Required: 1
TACHOMETER ASSY
No longer availableSearch Nationwide Inventory
$313.95
You save $34.88
-10%
2
Yamaha Motors
DAMPER 24A0-83541-00-00
Required: 1
SEAT, BATTERY
Supersedes: 1KT-82122-00-00
$4.37
You save $0.49
-10%
3
Yamaha Motors
Seat Damper3YF-24724-01-00
Required: 1
DAMPER
Supersedes: 4A0-83592-00-00
No longer availableSearch Nationwide Inventory
$3.92
You save $0.44
-10%
4
Yamaha Motors
WATER TEMP. ASY4A0-83590-01-00
Required: 1
WATER TEMPERATURE ASSY
No longer availableSearch Nationwide Inventory
$248.39
You save $27.60
-10%
$7.64
You save $0.85
-10%
No longer availableSearch Nationwide Inventory
$68.66
You save $7.63
-15%
7
Yamaha Motors
Screw98580-04010-00
Required: 5
SCREW, PAN HEAD
In stock
Only 2 remaining
$8.07
You save $1.42
-15%
8
Yamaha Motors
Spring Washer92990-04100-00
Required: 5
WASHER, SPRING
Supersedes: 92901-04100-00
In stock
5+ in stock
$0.81
You save $0.14
-50%
9
Yamaha Motors
Plate Washer92990-04600-00
Required: 5
WASHER, PLATE
Supersedes: 92901-04600-00
In stock
Only 1 remaining
$0.49
You save $0.49
-10%
$20.69
You save $2.30
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
