1998 Street Bike XJR1200SP - XJR1200SP (4PUB) [010] STARTER diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors XJR1200SP (4PUB) [010] - STARTER
Change View:
STARTING MOTOR ASSY
1
Yamaha Motors
STARTING MOTOR ASSY4KG-81800-00
Required: 1
STARTING MOTOR ASSY
Price unavailable
-10%
Tank Cap Gasket
3
Yamaha Motors
Tank Cap Gasket35C-81844-00-00
Required: 2
. GASKET
Supersedes: 11H-81844-00-00
Cross Ship
Leaves in 2-5 days
$53.99
$48.59
You save $5.40
More details
-10%
BOLT
4
Yamaha Motors
BOLT3AJ-81826-00-00
Required: 2
. BOLT
Cross Ship
Leaves in 2-5 days
$28.99
$26.09
You save $2.90
More details
-10%
Brush Set
5
Yamaha Motors
Brush Set3AJ-81801-00-00
Required: 1
. BRUSH SET
Cross Ship
Leaves in 2-5 days
$126.99
$114.29
You save $12.70
More details
-10%
BOLT, WASHER (4KG)
6
Yamaha Motors
BOLT, WASHER (4KG)90105-060A0-00
Required: 2
BOLT, FLANGE
Cross Ship
Leaves in 2-5 days
$9.49
$8.54
You save $0.95
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
