1999 Street Bike RX115 - RX115 (5FS2) [010] SEAT diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status

Click on

to see part

Ships Now

Ships Later

Out of Stock

Change View:

Yamaha Motors

DOUBLE SEAT ASSY52A-24730-00

Required: 1

DOUBLE SEAT ASSY

Price unavailable

Yamaha Motors

COVER, SEAT52A-24731-00

Required: 1

COVER, SEAT

Price unavailable

-10%

Yamaha Motors

SEAT PAD1L9-24741-00-00

Required: 4

PAD, SEAT

Supersedes: 174-24741-00-00

~~$10.99~~

$9.89

You save $1.10

More details

-15%

Yamaha Motors

Flange Nut95707-08500-00

Required: 2

NUT, FLANGE

~~$1.95~~

$1.66

You save $0.29

More details

Yamaha Motors

ASSIST, GRIP37L-2474A-00

Required: 1

ASSIST, GRIP

Price unavailable

Yamaha Motors

COVER, TAIL37L-24756-00-H9

Required: 1

COVER, TAIL

Price unavailable

Yamaha Motors

SCREW, WITH WASHER90159-06099

Required: 2

SCREW, WITH WASHER

Price unavailable

Yamaha Motors

HANDLE, SEAT37L-24773-00

Required: 1

HANDLE, SEAT

Price unavailable

-10%

Yamaha Motors

OIL OUTLET COVER1T4-24796-00-00

Required: 4

COVER

~~$5.49~~

$4.94

You save $0.55

More details

-10%

Yamaha Motors

SPECIAL SHAPE SCREW90149-08159-00

Required: 4

SCREW

No longer availableSearch Nationwide Inventory

~~$1.28~~

$1.15

You save $0.13

-10%

PLUG

No longer availableSearch Nationwide Inventory

~~$4.20~~

$3.78

You save $0.42

More details

Yamaha Motors

GRAPHIC SET, TAIL COVER4JF-2477M-01

Required: 1

GRAPHIC SET, TAIL COVER

Price unavailable

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
