2000 Street Bike V120JR-S - V120JR-S (4MA5) [010] FRONT BRAKE CALIPER 2 diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors V120JR-S (4MA5) [010] - FRONT BRAKE CALIPER 2
Change View:
DISK, BRAKE (RIGHT)
1
Yamaha Motors
DISK, BRAKE (RIGHT)3PP-F582U-00
Required: 1
DISK, BRAKE (RIGHT)
Price unavailable
-10%
BOLT,HEX. SOCKET BUT
2
Yamaha Motors
BOLT,HEX. SOCKET BUT90111-08084-00
Required: 4
BOLT
Supersedes: 90109-08718-00
Cross Ship
Leaves in 2-5 days
$6.49
$5.84
You save $0.65
More details
CALIPER ASSY (RIGHT)
3
Yamaha Motors
CALIPER ASSY (RIGHT)3YR-2580U-00
Required: 1
CALIPER ASSY (RIGHT)
Price unavailable
-10%
CALIPER PISTON ASSEMBLY
4
Yamaha Motors
CALIPER PISTON ASSEMBLY34X-W0057-00-00
Required: 1
. PISTON ASSY, CALIPER
Cross Ship
Leaves in 2-5 days
$139.99
$125.99
You save $14.00
More details
-10%
Caliper Seal Kit
5
Yamaha Motors
Caliper Seal Kit34X-W0047-00-00
Required: 1
. . CALIPER SEAL KIT
Cross Ship
Leaves in 2-5 days
$49.99
$44.99
You save $5.00
More details
-10%
BOOT
6
Yamaha Motors
BOOT5R2-25937-00-00
Required: 1
. BOOT 2
Cross Ship
Leaves in 2-5 days
$41.99
$37.79
You save $4.20
More details
-10%
BOOT
7
Yamaha Motors
BOOT34X-25937-00-00
Required: 1
. BOOT 2
Cross Ship
Leaves in 2-5 days
$34.99
$31.49
You save $3.50
More details
-10%
Bleed Screw Kit
8
Yamaha Motors
Bleed Screw Kit15B-W0048-00-00
Required: 1
. BLEED SCREW KIT
Supersedes: 51L-W0048-00-00
Cross Ship
Leaves in 2-5 days
$21.99
$19.79
You save $2.20
More details
-10%
Pad Support
9
Yamaha Motors
Pad Support34X-25919-00-00
Required: 1
. SUPPORT, PAD
Cross Ship
Leaves in 2-5 days
$62.99
$56.69
You save $6.30
More details
. BRAKE PAD KIT
10
Yamaha Motors
. BRAKE PAD KIT3YR-W0045-00
Required: 1
. BRAKE PAD KIT
Price unavailable
-10%
BOLT
11
Yamaha Motors
BOLT5KN-25926-01-00
Required: 1
. BOLT
Supersedes: 2GV-25926-00-00
Cross Ship
Leaves in 2-5 days
$9.49
$8.54
You save $0.95
More details
CAP, INDICATOR
12
Yamaha Motors
CAP, INDICATOR4MA-F5845-00
Required: 1
CAP, INDICATOR
Price unavailable

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
