2003 Street Bike FZS600 - FZS600 (5RT4) [050] REAR SUSPENSION diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors FZS600 (5RT4) [050] - REAR SUSPENSION
Change View:
SHOCK ABSORBER ASSY, REAR
1
Yamaha Motors
SHOCK ABSORBER ASSY, REAR5DM-22210-00
Required: 1
SHOCK ABSORBER ASSY, REAR
Price unavailable
-10%
Rear Shock Absorber Bushing
2
Yamaha Motors
Rear Shock Absorber Bushing2YK-22216-00-00
Required: 1
. BUSH, REAR SHOCK ABSORBER
Cross Ship
Leaves in 2-5 days
$80.99
$72.89
You save $8.10
More details
-10%
BOLT
3
Yamaha Motors
BOLT90109-10453-00
Required: 1
BOLT
Supersedes: 90109-10554-00
Cross Ship
Leaves in 2-5 days
$19.49
$17.54
You save $1.95
More details
-10%
Plain Washer
4
Yamaha Motors
Plain Washer90201-101J1-00
Required: 1
WASHER, PLATE
Cross Ship
Leaves in 2-5 days
$9.49
$8.54
You save $0.95
More details
-10%
NUT
5
Yamaha Motors
NUT95617-10100-00
Required: 1
NUT, U
Supersedes: 95607-10100-00
Cross Ship
Leaves in 2-5 days
$9.49
$8.54
You save $0.95
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
